Home > Banknote Counter > Back Feeding Bill Counter
Fake Banknote Detection LD-1683
Fake Banknote Detection LD-1683 Fake Banknote Detection LD-1683 Fake Banknote Detection LD-1683 Fake Banknote Detection LD-1683 Fake Banknote Detection LD-1683

Fake Banknote Detection LD-1683

Item No.: LD-1683
INQUIRY
Buy At Alibaba
Description Details Video Download
Features:
Automatic start, stop and clear.
UV (ultraviolet) detection: can detect banknotes with suspected UV properties, because fake notes often use white or bleached paper which will reflect UV light and make the surface of note very bright. Real banknotes can absorb UV light.
MG (magnetic) detection: can detect banknotes without MG properties, because most of banknotes are printed using magnetic ink.
Batch function: allows you to preset a specific number of bills that the machine will count up to.
Add function: allows cumulative counting of all bills, up to a maximum of 999 bills.
Automatic half-note, chained note, double-note detection.
Suitable for most currencies in the world.

Specifications:
Hopper Capacity: 150pcs
Stacker Capacity: 150pcs
Counting Speed: 1000pcs/min
Dimension: 316x270x193 mm
Power Supply: AC220V/110V 50Hz/60Hz
Power Consumption: 72W
Screen Type: TFT screen
Counting Display: 4 digits TFT
Batch Display: 3 digits TFT
Size of Countable Notes: 50x100-90x190mm
Thickness of Countable Notes: 0.075-0.15 mm
Continuous working time:>30 minutes
Work temperature:<20°C
Noise:<60dB
Product Net Weight: 6kg
Gross Weight: 14.8kg(2pcs)
Color Box Size: 375×316×250 mm
Outer Carton Size: 675x380x285 mm
Features Automatic start, stop and clear. √
UV (ultraviolet) detection: can detect banknotes with suspected UV properties, because fake notes often use white or bleached paper which will reflect UV light and make the surface of note very bright. Real banknotes can absorb UV light. √
MG (magnetic) detection: can detect banknotes without MG properties, because most of banknotes are printed using magnetic ink. √
Batch function: allows you to preset a specific number of bills that the machine will count up to. √
Add function: allows cumulative counting of all bills, up to a maximum of 999 bills. √
Automatic half-note, chained note, double-note detection. √
Suitable for most currencies in the world. √
To be with  screen display. TFT screen
Specifications Hopper Capacity(pcs) 150
Stacker Capacity(pcs) 150
Counting Speed(pcs/min) 1000
Power Supply(V) AC220V/110V 50Hz/60Hz
Power Consumption(W) 72W
Counting Display 4 digits LED
Batch Display 3 digits LED
Size of Countable Notes(mm) 50×100-90×190
Thickness of Countable Notes(mm) 0.075-0.15
Work Temperature(°C) <20°C
Noise(dB) <60dB
Continuous Working time(minutes) >30 minutes
Dimensions(mm)  270×316×197
Color Box Size(mm) 375×316×250
Net Weight(kg) 6
Carton Packing Details Dimensions (mm) 670×380×285
Volume (m³) 0.07
Gross Weight (kg) 14.8
Net Weight (kg) 12
Quantity(pcs ) 2
