Q: What does the CS-92 do?
A: The CS-92 counts and/or sorts coins per the specification table: 1500(max).
Q: What hopper or box capacity does the CS-92 have?
A: 4000pcs.
Q: How does the CS-92 display results?
A: 999999.
Q: What power supply does the CS-92 need?
A: AC120V±10% 60Hz or AC220V±10% 50Hz.
Q: Size and weight of the CS-92?
A: 420×230×360, net weight 12.5 kg.
Q: Does Easy-Banker accept OEM/ODM orders for the CS-92?
A: Yes. Easy-Banker manufactures currency counters, banknote sorters, coin sorters, money detectors, banding machines, POS terminals, printers and scanners. OEM/ODM customization is available - contact sales for MOQ, pricing and lead time.
Q: What after-sales support comes with the CS-92?
A: Engineering support, firmware/currency updates and spare parts from the Easy-Banker factory; distributors receive training material and remote commissioning assistance.
| Features | Increased flexibility allows processing of virtually any coin or token | √ | ||
| Higher productivity through high speed counting and simultaneous off-sorting of smaller coins | √ | |||
| Rugged construction gives increased durability | √ | |||
| Programmable bag stops | √ | |||
| Seven digits, clear LED display | √ | |||
| Quiet operation | √ | |||
| Employs reliable electronic counting system | √ | |||
| Direct, easy access to coin path with safety interlock system | √ | |||
| Specifications | Counting Speed | 1500(max) | ||
| Hopper Capacity | 4000pcs | |||
| Thickness | 1.0-3.4mm | |||
| Diameter | 15-34mm | |||
| Coin Type number | 1 | |||
| Max Counting Display | 999999 | |||
| Dimensions(mm) | 420×230×360 | |||
| Power Requirements | AC120V±10% 60Hz or AC220V±10% 50Hz | |||
| Power Consumption | 60W(during operation)27 | |||
| Carton Packing Details | Dimensions (mm) | 430×285×420 | ||
| Volume (m³) | 0.051 | |||
| Gross Weight (kg) | 13.7 | |||
| Gross Weight by Dimensions (kg) | 10.2 | |||
| Net Weight (kg) | 12.5 | |||
| Quantity(pcs ) | 1 | |||
